Electric cut-off ball valve
電動切斷球閥Composed of an electric actuator and a 0-type ball valve, DN15~200 is a floating ball structure, while DN250~300 is a fixed ball structure. The valve has a compact structure, small volume, light weight, easy assembly, disassembly and maintenance, smooth flow channel, low flow resistance, and good sealing performance. The valve seat adopts a flexible lip structure, which has wear compensation and automatic pressure relief in the middle chamber, thus ensuring reliable sealing and long service life. Widely used in industries such as petroleum, chemical, power, metallurgy, steel, papermaking, pharmaceuticals, food, textiles, and light industry.
技術參數和性能
|
型式 |
直通鑄造球型閥 |
|
公稱通徑 |
DN15、20、25、32、40、50、65、80、125、150、200、250、300 |
|
公稱壓力 |
PN1.6、2.5、4.0、6.4MPa |
|
法蘭標準 |
JB/T79.1(2)-94、GB/T9113.1(2)-2000 |
|
材料 |
鑄鋼ZG（230-450）、鑄不銹鋼（ZG1Cr18Ni9Ti、ZG1Cr18Ni12Mo2Ti） |
|
上腳蓋 |
與閥體成一整體-45~400℃ |
|
壓蓋型式 |
螺栓壓緊式 |
|
填料 |
V型聚四氟乙烯填料、含浸聚四氟乙烯石棉填料、石棉紡織填料、石墨填料 |
閥內組件
|
閥芯型式 |
球型閥芯 |
|
流量特性 |
快開特性 |
|
材料 |
鑄不銹鋼(ZG1Cr18Ni9Ti、ZG1Cr18Ni12Mo2T） |
|
額定行程 |
全開90° |
執行機構
|
型式 |
3410R、PSQ、HQ電子式電動執行機構 |
|
輸入信號 |
1-5V·DC |
|
電源電壓 |
220V/50HZ |
|
環境溫度 |
-20~+70℃ |
